The 5600 Series, a member of the POWERMATIC® Family of Operators, offers functionality and control at an affordable price. Ideal for retrofit applications, the 5600 Series converts interior, non-fire rated doors for ADA compliance easily and affordably and provides a simple way to achieve touchless environments in public restrooms. Available for push or pull mounting, this unit can be operated manually or activated by wall switches, or radio frequency devices. Easy to install, set-up and adjust, the 5600 Series is perfect for ADA-compliant offices, classrooms and dorm rooms, and touch free applications like public restrooms, labs and examination rooms.

• Quiet operation
• Electrically controlled backcheck, sweep and latch
• Activation options: wall switches, radio frequency devices
• Ease of installation and set-up
• On/Off Switch
• Hold open options: 0-30 seconds (5 seconds minimum required for ADA and ANSI/BHMA A156.19)
• Onboard 24VDC (1.1A) power supply for accessories
• Door closer mode for manual usage
• Electronic motor dampening - provides feel of high performance, manual door closer
• Electric hardware and access control interface
• Push & Go

- As the door is manually opened, the operator "senses" movement and opens door to the full-open position.

• Obstruction Detection

- Motor stops if door is obstructed during opening

• Motor Start Delay

- 0-5 second delay to allowing locking hardware to release first

• Overload Safety Shut-Off

- After two minutes of receiving a door activation signal, the unit will time out

- Prevents motor/inverter damage

• Executive™ Kit

- Operator is shipped with a transmitter and RF receiver

- Press the transmitter once and the door opens; press the transmitter a second time and the door closes
